HL5403, HL5404

Notes

Notas

CALIFORNIA PROPOSITION 65

You can create dust when

you cut, sand, drill or grind

materials such as wood,

paint, metal, concrete, cement, or other

masonry. This dust often contains

chemicals known to cause cancer, birth

defects, or other reproductive harm.

Wear protective gear.

This

product

or its power cord contains lead, a

chemical known to the State of

California to cause cancer and birth

defects or other reproductive harm.

Wash hands after handling.

Have the serial number, model number,

and parts list (with missing parts circled

before calling.)

General Safety

Information

Do not

operate

unit if damaged during shipping,

handling or use. Damage may result in

bursting and cause injury or property

damage.

Do not

run

unattended. Leaving compressor in

AUTO position may allow it to turn on

inadvertently. To prevent this and

possible damage from power surge,

turn to OFF position after each use.

Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.

Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or

property damage! Retain instructions for future reference.

Description

This oil-lubricated compressor is

designed for do-it-yourselfers with a

variety of home and automotive jobs.

These compressors power spray guns,

impact wrenches and other tools.

Compressed air from this unit will

contain moisture. Install a water filter or

air dryer if application requires dry air.

Safety Guidelines

This manual contains information that is

very important to know and understand.

This information is provided for SAFETY

and to PREVENT EQUIPMENT PROBLEMS.

To help recognize this information,

observe the following symbols.

Danger

indicates

an imminently hazardous situation

which, if not avoided, WILL result in

death or serious injury.

Warning

indicates

a potentially hazardous situation

which, if not avoided, COULD result in

death or serious injury.

aution

indicates

a potentially hazardous situation

which, if not avoided, MAY result in

minor or moderate injury.

Notice

indicates

important information, that if not

followed, MAY cause damage to

equipment.

Unpacking

After unpacking the unit, inspect

carefully for any damage that may have

occurred during transit. Make sure to

tighten fittings, bolts, etc., before

putting unit into service. In case of

questions, damaged or missing parts,

please call 1-800-543-6400 for customer

assistance.

Operating Instructions and Parts List HL5403, HL5404

IN626400AV 6/08

Breathable Air Warning

This compressor/pump is not

equipped and should not be used

“as is” to supply breathing quality

air. For any application of air for

human consumption, the air

compressor/pump will need to be

fitted with suitable in-line safety

and alarm equipment. This

additional equipment is necessary

to properly filter and purify the air

to meet minimal specifications for

Grade D breathing as described in

Compressed Gas Association

Commodity Specification G 7.1 -

1966, OSHA 29 CFR 1910. 134,

and/or Canadian Standards

Associations (CSA).

DISCLAIMER OF WARRANTIES

In the event the compressor is used

for the purpose of breathing air

application and proper in-line

safety and alarm equipment is not

simultaneously used, existing

warranties shall be voided, and the

manufacturer disclaims any liability

whatsoever for any loss, personal

injury or damage.

STOP!

Record the Model No., Serial No. and

date of purchase located on the base

below the pump in the space below.

Model No. ____________________

Serial No. ____________________

Date of purchase _________________

Retain these numbers for future

reference.

Oil Lubricated Compressors

DO NOT RETURN THE

PRODUCT TO THE

RETAILER!

See Warranty on page 10 for important information about commercial use of this product.

REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
